The solar photovoltaic lighting series products can provide multiple design schemes according to different on-site demands and actual situations.

The solar panels are made of monocrystalline silicon solar cells with an efficiency of 16% to 17%, enabling the modules to perform photoelectric conversion more effectively and having a service life of 25 years.Configure valve-regulated maintenance-free lead-acid batteries with relatively high cost performance;

Inquire Now Next Products

Product Overview

The specially designed controller features constant current mode, load short-circuit protection, reverse discharge protection, polarity reverse connection protection, lightning protection and charge and discharge protection.

The solar lighting system uses solar energy as its power source. It charges during the day and is used at night. There is no need for an external power supply. It is safe, reliable, green and energy-saving. The charging and on/off processes of the lights are intelligently controlled by a microcomputer. It automatically turns on when it gets dark and turns off when it gets light, without the need for manual operation, and has a long service life.

The solar lighting system is a fully automatic working system. As long as the working mode of this system is set, it can work automatically.

The control modes are generally divided into light control mode and timing control mode. Usually, light control or a combination of light control and timing is adopted for operation. When the light intensity is lower than the set value, the controller starts to light up the lamp and simultaneously begins timing. The light source turns off when the timing reaches the set time.

Technical Parameter

Item	Details
Solar street lamp Three-Proof LED Street lamp	CNAM-F-PV
Battery capacity	DC24V/80AH, DC24V/100AH, DC24V/150AH, DC24V/180AH
Controller	DC24V/10A, DC24V/20A, DC24V/20A, DC24V/20A
Product process	Electrostatic spraying
Protection grade	IP65
Installation height	6-12 meters(customizable)
Product accessories	Embedded parts
Applicable scenarios	Main roads/squares/rural areas, etc
Six core advantages	High-quality imported chips, high-transparency face masks, high-brightness lens headlamp beads, die-cast aluminum bodies, lithium iron phosphate batteries, standard diameter connectors.
Intelligent fully automatic light control	It lights up when it gets dark and turns off when it gets light. The fully automatic intelligent light control frees your hands. It has a timer for on and off and brightness adjustment.
The wide-angle lens emits light on three sides	The new super bright street lamp, one set is equivalent to three sets, with 330° light emission and no blind spots.
Duration of lighting	As bright as day, with an extremely long battery life. The traditional flat 60° illumination area is narrow, and the three-sided light emission provides 330° wide-angle illumination.
Large-capacity and long-lasting lithium battery	Small in size, large in capacity, long in service life, long battery life and fast charging.
Large-capacity and long-lasting lithium battery	Small in size, large in capacity, long in service life, long battery life and fast charging.
